| SPECIFICATIONS |
|
| The instrument complies with: EN61010-1. |
|
| Insulation: Class2, Double insulation. |
|
| Overvoltage category: CATIII 1000V, CATIV600V. |
|
| Display: 4000 s LCD display with function indication. |
|
| Polarity: Automatic, (-) negative polarity indication. |
|
| Overrange: “OL” mark indication. |
|
| Low battery indication: The “BAT” is displayed when the battery voltage drops below the operating level. |
| Measurement rate: 2 times per second, nominal. |
|
| Auto power off: Meter automatically shuts down after approx. 15 minutes of inactivity. |
| Operating environment: 0 oC to 50 oC (32 oF to 122 oF) at < 70 % relative huity. |
| Storage temperature: -20 oC to 60 oC (-4 oF to 140 oF) at < 80 % relative huity. |
| For inside use, max height: 2000m |
|
| Pollution degree: 2 |
|
| Power: One 9V battery , NEDA 1604, IEC 6F22. |
